Previous E10A solutions have been based on either PCIor PCMCIA and were dedicated to a particular device.
E10A-USB works differently inthat the hardware can support any H-UDI or AUD capable device.

You can selectwhich device family the E10A-USBwill support at installation. This is a One Time Process (OTP). The E10A-USB can be programmed to supportadditional device groups with a low-cost software upgrade available fromRenesas Development Tool suppliers. This means that only one hardware purchaseis necessary, thus reducing the cost of developing with Renesas devices now andin the future.

E10A-USB is supplied as a handy box withdebugging software and a connection cable.

Product Structure

The E10A-USB is supplied with the capability toinstall one Device Group, an additional purchase of one or more Device GroupAddition(s) enables the same E10A-USBto support devices from other Device Groups. Please view the Installationand Device Group Additions pages for further details.
E10A-USB emulator is connectedto the user system via the exclusive debug interface*1 (H-UDI*2 and AUD*3).That enables to debug in such an environment that is about equal to the actual.Using personal computer (IBM PC compatible) with USB 1.1/2.0 (Full-Speed) as ahost computer, E10A-USBemulator can debug not only in laboratory but also fields and anywhere.

*1: E10A-USBemulator is not support all the microcomputers which has the exclusive debuginterface (H-UDI and AUD).Please refer to the Target devices list.
*2: The H-UDI (User Debugging Interface) is an interface compatible with theJoint Test Action Group (JTAG) specifications.
*3: The AUD (Advanced User Debugger) is one of the emulator functions. The AUDhas Branch trace function and RAM monitoring function. As the emulator functiondepends on the emulator, please refer to the emulator manual to see if theemulator has the AUD function or not.

阵容

HS0005KCU01H

E10A-USB emulator not supporting AUD tracefunction.

HS0005KCU02H

E10A-USB emulator supporting AUD tracefunction.

HS0005KCU14H

E10A-USB emulator for the SuperH RISC engineFamily of multi-core MCUs supporting the synchronizing debugging function.
